Audiokultura Rytm: a vacuum tube phono preamplifier.
Features:
2x ECC88 & 2x ECC83 tubes
3 independent inputs:
– MM, classic 50dB tube input, compatible with most MM or MC-HO cartridges
– (external) Step-Up
– MC, input for MC cartridges with adjustable gain, from 60 to 71 dB
Independent load and capacity control for MM/SUT and MC inputs
Passive RIAA filter
Possibility of mono operation
Mute function
Double isolation of tubes and electronic systems from the environment:
– the motherboard is isolated from the housing using vibration isolators,
– the housing base is based on a specially selected rubber mixture
Dual output: RCA & XLR (2x DRV134)
Tubes power supply soft start system:
forty-second filament warm-up (from zero to 6.3V),
then gently increasing the anode voltage (from zero to 280V)
Control knob shafts mounted on bearings
The power supply is separated from the audio circuits
in a steel partition (Dual shielding system for the mains transformer)
Power consumption: 80W
Dimensions (width / height / depth): 430 x 130 x 260
Weight without packaging: 8kg (17,6lbs)
Weight including packaging: 10kg (22lbs)
